Description

Product Specifications:

Compatibility:

• Two modes of sampling: Whole blood, pre-diluted blood
• 4 USB, 1 LAN support protocol HL7 and compatible with LIS system
• Accompanying quality control material
• Auto-cleaning of sample probe and tubes
• Automatic fault processing function

Principles:

• Impedance method for RBC and PLT counting.
• Cyanide free reagent for hemoglobin test.
• Flow cytometry (FCM) + Tri-angle laser scatter method for WBC 5-part differential analysis and WBC counting

Detection Parameter:

The detection items include Reportable Parameters (21 items) : WBC, LYM%, MID%, GRAN%, LYM#, MID#, GRAN#, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW, PCT, P-LCR, P-LCC

3 histograms for WBC, RBC and PLT.

 Reagent:

• Diluent, Lyse for counting
• Probe Cleaner for maintenance

Throughput:

60 Sample/Hour.

Sample Volume:

Minimum volume 20µL.

Repeatability:

WBC≤2.0%, RBC≤1.5%, HGB≤1.5%, PLT≤4.0%, MCV≤1.0%.

Linearity Range:

WBC (0.00-300.00)×10⁹/L

RBC (0.00-8.50)×10ˉ12/L

HGB (0-250)g/L

PLT (0-3000)×10⁹/L

HCT 0.0-67.0%

Storage:

Up to 50,000 results including numeric and graphical.

Printout:

Built-in thermal printer supports various types of printer. Multi-built in print templates available.

Display:

10.4 inch TFT touch screen.

Input/output:

4 USB ports and Bi-directional LIS connection.

Operating environment:

Temperature 10°C to 30°C; relative humidity ≤ 85%.

Power Requirement:

100V-240V~ ; 50/60Hz.

Dimensions:

390mm(L)×285mm(W)×390mm(H)

Net Weight:

16 KG.
